12" 9-32V | 95W

22" 9-32V | 194W

32" 9-32V | 304W

42" 9-32V | 440W

50" 9-32V | 549W

• Type of lamp LED
• Voltage (V DC) 9-32V DC
• Theoretical lumen 8000
• Actual lumen 5078
• 1 LUX @ m 529
• IP-class IP67/69K
• Colour housing Black
• Colour lens Clear
• Colour LED´s White
• Beam pattern Combo
• Position light Yes white and orange
• Connection DT-4
• Cable length (mm) 500
• Material bracket Stainless steel
• Material housing/chassi Aluminium
• Material lens Polycarbonate
• Length (mm) 307
• Depth (mm) 71.6
• Height (mm) 76
• Height including bracket (mm) 89
• Operating temperature -20°C – +45°C
• ADR-approved No
• E-approved  Yes
• According to regulation ECE R112
• Reference number 37.5
• EMC ECE R10

Connection diagram:

• Black: - Earth
• Red: + LED bar
• Yellow: + amber position light
• White: + white position light
• Blue: + amber flash
